Automatic Bottle Caps Caps Printing Machine 2-Color 1600pcs/Min
Product Details:
| Place of Origin: | Dongguan China |
| Brand Name: | Senny |
| Certification: | CE,SGS |
| Model Number: | SOC2168 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Film wrapping |
| Delivery Time: | 45 days |
| Payment Terms: | T/T |
| Supply Ability: | 10pcs/month |
|
Detail Information |
|||
| Highlight: | 2-color automatic bottle caps printing machine,high-speed caps printing machine 1600pcs/min,automatic bottle caps printer with warranty |
||
|---|---|---|---|
Product Description
Automatic Bottle Caps Caps Printing Machine 2-Color 1600pcs/Min
PRODUCT
Features
Exceptional Printing Speed & Production Capacity Matching:
Steplessly adjustable printing speed for precise synchronization with customer production cycles.
Easily adapts to varying capacity demands – from low-speed fine proofing to high-speed mass production enabling seamless integration with cap injection molding machines or complete cap production lines.
Flexible Color Configuration & Precision Registration:
Modular design with multiple model options: Standard configurations include 1-2 color or 1-4 color units.
Equipped with a high-precision electronic shaft register system for perfect multi-color registration (registration accuracy: ±0.05mm), ensuring sharp, clear reproduction of complex patterns and fine text without ghosting.
Accurate and Controllable Ink Layer System:
Independently adjustable inking system: Each printing unit features a precision ink metering mechanism.
Stepless ink film thickness control: Operators can precisely and easily adjust UV ink deposition to meet varying process requirements – from ultra-thin base layers to heavy coverage – guaranteeing color saturation and consistency.
Intelligent Operation & Convenient Maintenance:
Electronically controlled reverse operation: Simplifies setup, cleaning, and troubleshooting, significantly enhancing operational convenience.
Removable console: Ergonomic design allows flexible positioning for optimal operator interaction.
User-friendly Human-Machine Interface (HMI): Features a large color touchscreen with an intuitive graphical interface for clear parameter setting, status monitoring, and fault diagnosis.
Stable & Reliable Electrical & Control System:
Premium brand components: Critical electrical elements (e.g., PLCs, servo drives, inverters, sensors) utilize internationally renowned brands like Siemens, Omron, and Schneider, ensuring long-term stable operation.
Advanced control system: Based on a high-performance PLC (Programmable Logic Controller)core, integrated with HMI and servo drive technology for precise motion control, rapid response, and reliable logic.
High stability & low failure rate: Optimized system design and rigorous component selection guarantee exceptional reliability and extended service life in continuous production environments.
Technical parameters
| Machine Model | SOC2168 | SOC4328 |
| Cap Diameter | 28mm-38mm | 28mm-38mm |
| Max Speed | Up to 1600Pcs/Min | Up to 3200Pcs/Min |
| Printing Color | 2-4 color | 2-4 color |
| Printing Area | 24mm-34mm | 24mm-34mm |
| Air Consumption | 600L/Min | 600L/Min |
| Gas Consumption | 150L/Min | 150L/Min |
| Power | 3p 380v 50/60Hz | 3p 380v 50/60Hz |
| Air | 5-7 Bar | 5-7 Bar |
Configuration
- Plasma surface treatment(standrad condiguration is flame surface treatment)
- Bottle sorting machine
- Quanlity inspection machine
UV curing flame tratment device
Applications
SOC2168 Automatic Bottle Cap Dual-Color UV Offset Printing Machine is a fully automatic bottle cap dual-color UV offset printing machine. The application scope is very widely and it can be used for high-precision UV offset printing of various plastic bottle caps such as PCO1881, PCO1810, 28mm, 38mm caps; PP caps, PE caps, PET caps, cosmetic caps, pharmaceutical caps, beverage caps, etc.
About us
SENNY PRINTING EQUIPMENT CO.,LTD was established in the year 2004, it is specialized in designing and manufacturing precise automatic screen printing machines, stick labler machines, hot stamping machines and auxiliary equipments. Meanwhile, they can design any kinds of automatic printing machines according to customers' requirements.
SENNY has very good designers. The founder of SENNY was engaged in designing and developing screen printing machines early from the year 1994, and he got many achievements: he designed the first automatic screen printing machine; automatic screen printing machine for big iron pails; four colors sereen printing machine for big oil kettles; automatic screen printing machines controlled by module independently for bottles; automatic screen printing machine for pails from 10L 1o 20L(3colors and 7colors) and so on so forth.
In order to improve our products, SENNY adopts the advantages of the similar products in or abroad, and we also take customers' comments and suggestions into consideration. With the innovation and improvement for many years, the products produced by SENNY now are in a leading position in the domestic markets. And it also sales well all around the world.
With the mission“Excellence,Creation,Sincerity,Quality!”,SENNY insists on providing high--quality products and services, dedicating to exploring the new markets and seeking for mutual benefit and win-win state with our customers.
