Maintenance Efficiency Tube Screen Printing Machine For Soft Tubes 85pcs/Min
Product Details:
| Place of Origin: | Dongguan China |
| Brand Name: | Senny |
| Certification: | CE,SGS |
| Model Number: | SRS566 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Film wrapping |
| Delivery Time: | 45 days |
| Payment Terms: | T/T |
| Supply Ability: | 10pcs/month |
|
Detail Information |
|||
| Minimum Order Quantity: | 1PC | Price: | Negotiation |
|---|---|---|---|
| Packaging Details: | Plywood Package | Delivery Time: | One Month |
| Payment Terms: | T/T | Supply Ability: | 10pcs/month |
| Package Details: | Plywood Package | Certification: | CE SGS |
| After-Sales Service: | Video Or On-line | ||
Product Description
Maintenance Efficiency Tube Screen Printing Machine For Soft Tubes 85pcs/Min
PRODUCT
Machine Features
1. Core: Drive Control, Precision & Stability
The equipment is equipped with a high-torque, low-noise servo motor drive system, paired with an industrial-grade chip-based high-precision digital control system. This setup enables precise adjustment of key printing parameters (e.g., printing speed, pressure, stroke length, and printing gap), avoids pattern deviations caused by parameter fluctuations, and ensures highly consistent printing actions every time. It operates stably without jitter during continuous full-load operation (e.g., 8+ hours), with a repeat positioning accuracy of ±0.02mm—fully meeting strict standards for fine patterns (such as lines <0.1mm wide) and multi-color overprinting (overprint error controlled within 0.03mm).
2. Core: Operational Flexibility & Convenience
Operation is flexible and user-friendly: it features a fixed high-definition touchscreen for on-site intuitive operation and parameter modification, plus a mobile wireless tablet control system for remote monitoring of equipment status and process parameter adjustment. Combined with an exclusive remote service module, engineers can perform maintenance tasks (e.g., fault diagnosis, program upgrades) without being on-site, greatly improving operation and maintenance efficiency.
3. Core: Component Quality & Long-Term Reliability
Core electrical components are all carefully selected from international first-tier brands (e.g., Schneider, Omron), covering key parts such as electromagnetic relays, photoelectric sensors, programmable logic controller (PLC) modules, and servo drives. All components undergo strict quality inspection and performance testing before delivery, including high-low temperature environmental adaptability testing, continuous load operation stability testing, and anti-interference capability verification. This rigorous screening ensures stable and reliable equipment performance even in long-term high-load industrial scenarios (e.g., daily operation of 12+ hours). It not only increases the equipment’s Mean Time Between Failures (MTBF) by over 30% but also significantly extends the service life of core components, reducing subsequent equipment maintenance costs.
Technical parameters
| Mechine Model | SRS566 |
| Work Station | 8 |
| Printing speed | Up to 85pcs/min |
| Soft Tube Diameter | 13-76mm |
| Printing Color | 1+4 |
| Max Printing Length | 30-240mm |
| Max Printing Height | 180mm |
| Printing Accuracy | ±0.1mm |
Configuration
- Unscrambling&feeding machine Hot stamping function plasma surface treatment function
- Visual registration function LED-UV curing function Finished product quality inspection function
Silk screen printing head
UV curing
Feeding device
Applications
SRS566 CNC Tubular UV Screen Printing Machine is a fully automatic four-color device, optimized for fine printing on cosmetic and skincare hoses. Its core advantage is precise four-color overprinting, capable of rendering rich colors and smooth gradients, suitable for complex designs like brand color logos, gradient patterns, and detailed ingredient lists.
It applies to various cylindrical or slightly tapered hoses (e.g., facial cleansers, serums, lotions, creams, sunscreens), handling curved fine printing on PE, PP, composite materials, etc. The UV curing system ensures strong adhesion, friction resistance (adapting to frequent squeezing during use), and a smooth, high-end finish, meeting cosmetics' strict requirements for vivid colors, design fidelity, and durability.
Printing Sample
