8-Color 85 Pcs/Min CNC Soft Tubes UV Screen Printing Machine
Product Details:
| Place of Origin: | Dongguan China |
| Brand Name: | SENNY |
| Certification: | CE SGS |
| Model Number: | SRS866 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | negotiation |
| Packaging Details: | Plywood package |
| Delivery Time: | 45days |
| Payment Terms: | T/T |
| Supply Ability: | 10 pcs/month |
|
Detail Information |
|||
| Plate Type: | Screen Printing Machine | Printed Color: | 8 Colors |
|---|---|---|---|
| After-sales Services: | Video Or On-line | Delivery Time: | 45days |
Product Description
Machine Feature
- This machine is suitable for decorating plastic soft tubes through processes such as multi-color UV ink screen printing, hot stamping, and varnishing.
- The SRS866 features an integrated turntable design—all printing functions are completed using the same set of fixtures, enabling printing accuracy as high as ±0.1mm.
- Driven by a digitally controlled servo motor, the SRS866 achieves 360-degree printing on products. It is also equipped with remote management and service capabilities, aligning with Industry 4.0 standards.
- In terms of performance and operation, the machine adopts electrical components from well-known brands and a PLC control system. It also supports user-friendly operation via a touch screen and wireless tablet, ensuring reliable overall performance.
Optional Configuration
Unscrambling & feeding machine. Hot stamping function. Plasma surface treatment function.
Visual registration function. LED-UV curing function. Finished product quality inspection function.
Technical Parameters
| Machine Model | SRS866 |
| Printing color | 1-8 color |
| Printing speed | Up to 85 pcs/min |
| Soft tube diameter | 13-80mm |
| Soft tube Height | 25-250mm |
| Max.Printing Length | 250mm |
| Max.Printing Height | 220mm |
| Printing Accuracy | ±0.1mm |
Printing your vision
About us:
Since its establishment in 1994, Senny has consistently adhered to the business philosophy of delivering high-quality products and services to customers. It utilizes the most advanced electrical control components and materials for research, development, and manufacturing, while continuously enhancing the printing quality of diverse products. This commitment allows Senny to meet the ever-expanding market demands for high-quality packaging.
